$33.99
The Eryone High-Speed Silk PLA is a material with a thoroughly improved
formulation, offering significantly enhanced printing speeds compared to standard silk
PLA, reaching up to 500 mm/s. Additionally, its tensile strength has been notably
increased, with the Z-axis tensile strength reaching 20 MPa. This high-speed silk PLA
material delivers a more lustrous finish, presenting a silk-like appearance. The
brightness can be controlled by adjusting the temperature and speed: higher
temperatures and slower printing speeds result in increased brightness.
| Parameter | Set up |
| Nozzle temperature | 190℃-220℃ |
| Bed temperature | 55-70℃ |
| Bed material | glass, PEI, spring steel plate |
| Bottom printing temperature | 190℃-220℃ |
| Sealed printing | Open Printing/closed printing |
| Printing speed | 30-500mm/s |
| Drying conditions | 65℃-75℃，12H |
| Property | Testing Method | Unit | Typical Value |
| Density(g/cm³ at 21.5 ° C） | ASTM D792 (ISO 1183, GB/T 1033) | g/cm³ | 1.32 |
| Vicat Softening Temperature(° C) | ASTM D1525 (ISO 306 GB/T 1633) | ℃ | 56 |
| Heat distortion temperature(° C | ASTM D648 1.8MPa 0.45MPa | ℃ | 50 |
| Glass transition temperature (° C) | DSC, 10 ° C/min | ℃ | 57 |
| Melt Index(g/10 min) | 220 ° C, 10kg 240 ° C, 2.16 kg | g/10min | 20±1.5 |
| Property | Test conditions | Test standards | unit | Typical Value |
| Tensile strength X-Y | 50mm/min | GB/T 1040.4 | MPa | 62.7 |
| Elastic modulus X-Y | 50mm/min | GB/T 1040.1-2006 | MPa | 1932.1 |
| Elongation at break X-Y | 50mm/min | GB/T 1040.4 | % | 2.3 |
| Tensile strength X-Z | 50mm/min | GB/T 1843 | MPa | 19.1 |
| Elastic modulus X-Z | 50mm/min | GB/T 1040.1-2006 | MPa | 1873.5 |
| Elongation at break X-Z | 50mm/min | GB/T 1040.4 | % | 1.9 |
| Bending strength | 2mm/min | GB/T 9341 | MPa | 86.7 |
| Bending modulus | 2mm/min | GB/T 9341 | MPa | 2917.3 |
| Charpy Impact strenght | 2.75J | GB/T 1843 | kJ/m2 | 3.8 |
| Weight | 1.4 kg |
|---|---|
| Dimensions | 21 × 22 × 7 cm |
| Colour: | Twilight Glow (Black & Red & Deep Purple & Gold), Electrical Night(Neon Purple & Bright Blue & Neon Pink & Neon Yellow), Royal Essence (Black & Purple & Silver & Dark Green), Metallic Frenzy (Black & Dark Red & Banana Orange & Gold), Evil Pool(Red & Purple & Blue & Green ) |
